VTS02 Series Temperature and Humidity Sensors

Features

Enhanced Security and Network stability: Compliant with ZigBee PRO certified platform
Low Power Consumption: lithium thionyl Chloride (Li-SOCl₂) Battery ER14335 with up to 5 years’ service life.
IP68 Rated: Completely sealed waterproof design.

Applications:

Cold Chain Transportation	Walk-in Freezers
Refrigerators	Walk-in Coolers
Cold Storage	Supermarkets
Pharmacies	Laboratories / Medical Institutions
Warehouses	Restaurants

Wireless Temperature Sensor

Basic Parameters

Model	VTS04W02
Operating temperature	-40℃ ~ 85℃
Temperature Range	-40℃ ~ 85℃
Humidity range	/
Resolution	0.01℃
Measurement accuracy	±0.5℃
Network coverage distance	Outdoor:200m
	Indoor:30m ~ 50m
Way of communication	ZigBee
Service life	5 years (5-minute intervals)

External Probe Temperature Sensor

Basic Parameters

Model	VTS05-2
Operating temperature	-40℃ ~ 85 ℃
Temperature Range	-40 ℃ ~ 105℃
Humidity range	/
Resolution	0.01℃
Measurement accuracy	±0.5℃
Network coverage distance	Outdoor:200m
	Indoor:30m ~ 50m
Way of communication	ZigBee
Service life	5 years (5-minute intervals)

Temperature Humidity Sensor

Basic Parameters

Model	VTS02-3
Operating temperature	-40℃ ~ 85℃, 0~100% RH
Temperature range	-40℃ ~ 85℃
Humidity range	0 ~ 100%RH
Resolution	0.01℃/0.04%RH
Measurement accuracy	±0.5℃/±5%RH
Network coverage distance	Outdoor:200m
	Indoor:30m ~ 50m
Way of communication	ZigBee
Service life	5 years (5-minute intervals)
